Haier HC27SF10RB - Chapter 3 Disassembly; Thermostat Disassembly

.
SERVICE
MANUAL
Model: HC17SF10RB/HC27SF10RW/B
7
Issue 2014-3-10
Rev. Ref1403S005V0
Chapter 3 Disassembly
3-1. Thermostat disassembly
1
First take down the thermostat knob
2 Unscrew the screw like the picture
3 Take down the wire groove
4
Rotate the thermostat axes
counter-clockwise and take down the
thermostat
