Freezer Door:
(see fig. # 1)
1. Remove hinge cover screw.
2. Remove the top hinge cover.
3. Loosen the top hinge screws using a phillips head screwdriver.
4. Adjust the door or put a spacer in between and then tighten the screws.
5. Replace the top hinge cover.
Refrigerator Door:
(see fig. # 2)
1. Loosen and remove the bottom hinge using a
phillips head screwdriver.
2. Adjust the door, or put a spacer in between and
then tighten the screws.
Door Alignment
7
fig. # 1
Hinge box
cover
Top hinge
Bottom hinge axle
Plastic pad
Bottom hinge pad
Bottom hinge
fig. # 2
English English
