Haier HL19D2 User Manual

55
AM1G1740 10225 CR3 SCREW
Q12G6082 3 FOOT PAD
705TQ949001 COMSUPTIVE ASS'Y-A4
E750 750TVU185X125QN000 PANEL M185XW01 V2TB FQ AUO
756TQACB ZK021 01 MAIN BOARD-CBPFAZ7KQ5
U201 056G1133 34 M24C02-WMN6TP
U201 056G1133918 IC AT24C02BN-SH-T 8-SOIC
U404 056T1133935 IC MX25L3205DMI-12G SOP-16
SMTF-U404 100TZZV9002K11 MCU ASS'Y(056T1133935)
SMTF-U201 100TZZV9V01K1E MCU ASS'Y(056G1133918)
A15T0512101 MAIN FRAME
AM1G1740 10225 CR3 SCREW
040G 45762412B CBPC LABEL
CN604 033G3802 4B Y L CONN 2.0 4P
CN407 033G3802 9B Y CONNECTOR 9P 2.0
CN407 033G3802 9B Y L CONN 2.0 9P
CN701 033T327812D WAFER 12P PLUG
CN604 033T3802 4B Y CONNECTOR
040G 457624 1B LABEL-CPU
R726 061G153M22059E SY RST MOFR 22 OHM +-5% 3WS
C692 067G215H221 3C EC 220UF 16V SY 8X7MM
CN605 088G 30211K PHONE JACK 5PIN
CN605 088G 302A11 YG PHONE JACK 3.5¦µ 7PIN BLACK CKX3.507B-01
CN402 088G 352 2 YG USB CONNECTOR USB4-01
CN402 088G 352 21CL USB CONN TYPE A
CN601 088T 78 1357C RCA JACK 1*1 W+R V/A
CN606 088T 78 1357C RCA JACK 1*1 W+R V/A
CN202 088T 78 1360C RCA JACK 1*3 G/BL/R V/A
CN201 088T 78 13932 C RCA JACK + S JACK Y/B
CN202 088T 78 13A36 YG RCA JACK 1*3 G/BL/R V/A RCA-346D-02
CN601 088T 78 13A37 YG RCA JACK 1*2 W/R V/A RCA-276D-01
CN606 088T 78 13A37 YG RCA JACK 1*2 W/R V/A RCA-276D-01
CN603 088T 30252C PHONE JACK 3.5MM 3P V/A GREEN
CN603 088T 302A17 YG PHONE JACK 3.5MM 3P V/T GREEN
CN203 088T 35315F VC D-SUB 15PIN VERTICAL CONNECTOR
CN203 088T 35315FVSD D-SUB 15PIN VERTICAL CONNECTOR
CN602 088T 359 5 JT FIBER-OPTIC 3P V/T JST1227
X401 093G 2262B J XTL NXS25.000AC20F-KAB5-3 HC-49/US
TU202 094GNTAT MA9MA TUNER NTSC+ATSC ENV56U01D8F
CN406 311GW200C30AAL WAFER 2.0MM 2*15P
A85T0144101 EMI SHIELD-BTM-NA FOR U401
A85T0145103 SHIELD FOR U401
C751 067G 2151007NT KY50VB10M-TP5 5*11.5
C752 067G 2151007NT KY50VB10M-TP5 5*11.5
C751 067G 2151007RT LOW E.S.R 10UF +/-20% 50V
C752 067G 2151007RT LOW E.S.R 10UF +/-20% 50V
C769 067G 2152213HT 220UF 16V
C763 067G 2152213HT 220UF 16V
C762 067G 2152213HT 220UF 16V
C739 067G 2152213HT 220UF 16V
C731 067G 2152213HT 220UF 16V
C727 067G 2152213HT 220UF 16V
C721 067G 2152213HT 220UF 16V
C704 067G 2152213HT 220UF 16V

Haier HL19D2 Specifications

General

Brand	Haier
Model	HL19D2
Category	LCD TV
Language	English
