Page #21 background imageLoading...
Page #21 background image
Remove the twelve screws indicated by the
blue lines in below picture.
3-2-8. Remove the Speaker
Service Manual
Model No.:
20
3 Screws(ST3*10)
3-2-6. Remove the Lcd panel
off the front frame
6 Screws(ST4*12)
3-2-7. Remove the key board
and remote board
