Key connector (CNE2)
1
2
3
Pin number
Signal name
Description
GND GND
KEY0 KEY0
KEY1 KEY1
Power of audio anplifier connector (CNA2)
1
2
3
Pin number
Signal name
Description
GND
L+
GND
4
R+
GND
Left of audio
GND
Right of audio
Power connectors (CNA1)
Pin number
Signal name
Description
5
6
7
ON/OFF
PW-ON/OFF
GND
GND
5VS
5V-Stand
GND
GND
GND
GND
12VA
12V-Mainboard
12VA
12V-Mainboard
1
2
3
4
4-2-2-2.Connector definition
1
2
3
4
Back light connectors (CNF1)
Pin number
Signal name
Description
ADJ
PBON
GND
5V
Back light adjust
Back light ON/OFF
GND
5V
