Service Manual
Model No.:
7-3-3.LB42R3
1
2
3
4
5
6
7
8
NO. Name Parts number
1
Connection Wire(Control of Sensitization )
2
3
Connection Wire(For Keyboard)
4
Connection Wire(For Speaker)
5
Connection Wire(Power For Audio Amplifier)
6
Connection Wire(For Remote)
7
LVDS Wire
8
Connection Wire(Power For Mainboard)
Connection Wire(For Back Light)
0090401850B
0090402750A
0090401643E
0090401752
0090403469D
0090402724A
55
0090403399B
0090402054
To Next Page
