Haier HMV1472BHS User Manual

a
A
Screws (2)
4. Remove the used charcoal lter from the back of the grille, and then discard the
lter.
5. Align the holes in the new charcoal lter with the ve posts on the back of the
grille, and gently press down to attach.
a
A
Charcoal Filter
6. Align the top edge of the grille so that when the grille is pushed into place the
screw hole tabs on the the grille will align with the holes in the microwave
cabinet. Gently push on the grille until it snaps into place and the screw holes
are aligned.
NOTE: Make sure that the wire harness, located near the door hinge, is
not pinched when you are replacing the top grille.
a b b
A
Wire Harness (not shown)
B
Screw Hole Tab (2)
7. Replace the two screws removed earlier, and completely tighten the screws.
16
ENGLISH

Haier HMV1472BHS Specifications

General

Brand	Haier
Model	HMV1472BHS
Category	Microwave Oven
Language	English
