Haier HP150M5 User Manual

7
Technical parameters
Model
HP150M5
Tank volume 150L
Rated voltage/ frequency 220V~240V/50Hz
Tank rated pressure 0.8MPa
Corrosion protection Magnesium rod
Water proof grade IPX4
Type of extraction Ambient / Exterior
COP@7
℃
/ EN16147 2.99
COP@14
℃
/ EN16147 3.58
Tapping cycle L
Power input by electric backup 1200W
Rated power input by heat pump 240 W
Maximum power input by heat pump
350W
Maximum power input
1550W
Standby power input/ Pes
20W
Max volume of usable hot water at 40
℃
setting at 55℃
195.9L
Heating up time (7
℃)
10h29
Heating up time (14
℃) 8h28
Default temperature setting
55
℃
Temperature setting range- with heater 35℃-75℃
Maximum length of air duct
160mm
Max working pressure of refrigerant 0.8/2.8MPa
Refrigerant type / weight R134a/0.46kg
Sound power level 50dB
(A)
Ambient temperature for use of product -7~45
℃
Operating temperature of heat pump -7~45℃
Water inlet and outlet connection G1/2"M
Safety valve connection G1/2"M
Drain & Water intle
t connection G1/2"M
Product Dimensions
492*537*1680mm
Packing dimension without pallet 587*587*1764mm
Tank
Performances
Dimension and connections
English
Diameter of air duct connection
5m
Net/Gross weight 67/89kg
Packing dimension without pallet
587*587*1894mm
The COP values obtained with external air temperature of 7°C and 14°C, inlet water temperature
of 10°C and set temperature of 54°C (according to EN 16147).
* The COP and noise level data was tested in Haier lab.
