Installation introduction
Installation dimensions(external unit
English
13
50mm
500mm
Air inlet
300mm
600mm
300mm
1500mm
Air outlet
500mm
H
2/3H
The strap of tank
Installation dimensions(tank unit
Expansion bolts
