5
English
Parts and Features
1. Air Outlet
2. Van Air Deflector
3. Front Panel
4. Control Panel
5. Side Panel
6. Caster
1. Screen Filter
2. Air Intake (Evaporator)
3. Air Outlet (Heat Exchange)
4. Air Intake (Condenser)
5. Power Supply Cord
6. Water Outlet Drain
1
4
6
5
3
2
1
2
3
4
6
5
1. Full-Tank Indicator
See the trouble shooting when the light is on.
2. Set-Up of Function Key
Cool: Lamp is on when in cooling mode.
Dehumidifier: Lamp is on when in dehumidification
mode.
Fan: Lamp is on when in fan mode.
3. Temperature & Timer set-up key
a) Time on or time off mode:
Timer setting (1-12 Hours)
b) Cooling or Dehumidification mode temperature set-
ting.
4. Power Key
On/Off
5. Fan Speed Key
HIGH MED LOW
6. On/Off Timer Key
In running mode: Auto Switch Off
In stand by mobde: Auto Switch On
1
2
3a 3b
65
4
