Haier HR18D2VAE - Page 5

Figure 1
3
D
W
H
Table2: System Capacity
cooling
heating
Capacity SEER CFM 80 85 90 95 100 105 110 115
HR18
D2VAEHB2400VD2M20M18000136702034019746190801800017730174601719016920
HR24
D2VAEHB2400VD2M20H24000139002712026328254402400023640232802292022560
HR30D2VAE HB3600VD2M20-T L 30000 13 1125 33900 32910 31800 30000 29550 29100 28650 28200
HR36D2VAE HB3600VD2M20-T H 34000 13 1300 38420 37298 36040 34000 33490 32980 32470 31960
HR42D1VAEHB4800VD3M22L410001314804633044977434604100040385397703915538540
HR48D1VAEHB4800VD3M22H475001315605367552108503504750046788460754536344650
HR60D1VAE HB6000VD1M22-T H 57500 13 1730 64975 63078 60950 57500 56638 55775 54913 54050
ARI data of indoor Cooling Capacity with different outdoor temperature
Outdoor Indoor Indoor fan speed
Capacity HSPF CFM -10 0 10 20 30 40 50 60
HR18D2VAEHB2400VD2M20M168007.76705568748893761129513152154741823221000
HR24D2VAEHB2400VD2M20H220007.790070009413117871420016533194532292026400
HR30D2VAE HB3600VD2M20-T L 27800 7.7 1125 8845 11895 14894 17944 20892 24582 28963 33360
HR36D2VAE HB3600VD2M20-T H 32000 7.7 1300 10182 13692 17144 20655 24048 28296 33338 38400
HR42D1VAEHB4800VD3M22L410007.714801304517543219662646430812362544271549200
HR48
D1VAEHB4800VD3M22H475007.715601511420324254483065935697420014948657000
HR60
D1VAE HB6000VD1M22-T H 57000 7.7 1730 18136 24389 30538 36791 42836 50402 59384 68400
Outdoor Indoor Indoor fan speed
ARI data of indoor Heating Capacity with different outdoor temperature
