Haier HRF-661RSSAA User Manual

Door removal
Remove the refrigerator compartment
door.
1)Loosen the hinge cover bolts, and then
remove the cover. Disconnect any wires
except for the grounding wire.
3)Lift the refrigerator compartment door to
remove it.
2) Remove the screws from the upper hinge
following the direction as indicated by Arrow (1).
Then remove the upper hinge following the
direction as indicated by Arrow (2).
Wires
Upper hinge
Screw
Lower hinge
Slide the refrigerator through the
door opening.
Slide the refrigerator through the door
opening as shown in the illustration.
Reinstall the door.
Bring the doors in the house, and then
reinstall them by reversing the removal steps.
11

Haier HRF-661RSSAA Specifications

General

Product color	Stainless steel
Built-in display	LCD
Appliance placement	Freestanding
Number of compressors	1
Icemaker	Yes
Noise level	42 dB
Climate class	SN-ST
Total net capacity	500 L
Total gross capacity	541 L
Multi-airflow system	-
Star rating	4*
Freezing capacity	10 kg/24h
Freezer net capacity	159 L
Freezer gross capacity	- L
Freezer number of shelves/baskets	3
Storage time during power failure	5 h
Fridge net capacity	341 L
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Annual energy consumption	412 kWh
Package depth	770 mm
Package width	960 mm
Package height	1894 mm
Package weight	130000 g

Weight and Dimensions

Depth	670 mm
Width	890 mm
Height	1770 mm
Weight	120000 g
