Haier HRF-661RSSAA User Manual

Dispenser operation
Dispenser operation
Choose crushed ice, refrigerated water or ice cubes. Slightly push a glass against the ice/water lever as
shown in the illustration.
(1) Dispensing crushed ice
Press the appropriate button so that the
indicator for crushed ice lights up.
Lightly press against the lever so that
crushed ice is supplied.
(2) Dispensing ice cubes
Press the appropriate button so that the
indicator for ice cubes lights up.
Lightly press against the lever so that ice
cubes are supplied.
(3) Dispensing refrigerated water
Press the appropriate button so that the
indicator for refrigerated water lights up.
Lightly press against the lever so that
refrigerated water is supplied.
Dispensing crushed ice
Even with the ice cube option selected, some crushed ice may be supplied simultaneously. It is also
possible that the crushed ice supply is mingled with a few ice cubes.
When crushed ice is frequently called for, it is normal for frost to build up around the outlet, but it
will eventually evaporate.
Keep the glass close to the dispenser to prevent ice from spilling.
Dispensing refrigerated water
Due to air in the water supply line, refrigerated water may not be available immediately after
installation. In this case, hold the dispenser lever pressed in for as long as two minutes to evacuate
any remaining air.
After that, the supplied water will become increasingly cooler.
Refrigerated water does not contain any ice cubes. To lower the temperature of the refrigerated water,
add crushed ice or ice cubes to it.
Caution: Keep fingers and objects away from the dispenser.
29

Haier HRF-661RSSAA Specifications

General

Product color	Stainless steel
Built-in display	LCD
Appliance placement	Freestanding
Number of compressors	1
Icemaker	Yes
Noise level	42 dB
Climate class	SN-ST
Total net capacity	500 L
Total gross capacity	541 L
Multi-airflow system	-
Star rating	4*
Freezing capacity	10 kg/24h
Freezer net capacity	159 L
Freezer gross capacity	- L
Freezer number of shelves/baskets	3
Storage time during power failure	5 h
Fridge net capacity	341 L
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Annual energy consumption	412 kWh
Package depth	770 mm
Package width	960 mm
Package height	1894 mm
Package weight	130000 g

Weight and Dimensions

Depth	670 mm
Width	890 mm
Height	1770 mm
Weight	120000 g
