Haier HRF-661RSSAA User Manual

Door removal
Removing the door
If your house door is too narrow, remove the refrigerator door and carry the
refrigerator in narrow side first.
Remove the toe moulding, and then
release the water coupler.
Slide the toe moulding up to remove it, and then release
the water coupler while pressing on area (1) as shown in
the illustration.
Water coupler
Toe moulding
Remove the freezer compartment door.
1) Unscrew the hinge covers. Disconnect all
wires except for the grounding wire.
2) Remove the screws from the upper hinge
following the direction as indicated by Arrow (1).
Then remove the upper hinge following the
direction as indicated by Arrow (2).
3) Lift the freezer compartment door to remove
it. Next, lift the door enough to be able fully
pull out the water line.
Hinge cover
Wires
Upper
(hinge)
Grounding wire
Upper hinge
Screw
Lift
Lift until water
line can be fully
removed.
Lower
hinge
10

Haier HRF-661RSSAA Specifications

General

Product color	Stainless steel
Built-in display	LCD
Appliance placement	Freestanding
Number of compressors	1
Icemaker	Yes
Noise level	42 dB
Climate class	SN-ST
Total net capacity	500 L
Total gross capacity	541 L
Multi-airflow system	-
Star rating	4*
Freezing capacity	10 kg/24h
Freezer net capacity	159 L
Freezer gross capacity	- L
Freezer number of shelves/baskets	3
Storage time during power failure	5 h
Fridge net capacity	341 L
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Annual energy consumption	412 kWh
Package depth	770 mm
Package width	960 mm
Package height	1894 mm
Package weight	130000 g

Weight and Dimensions

Depth	670 mm
Width	890 mm
Height	1770 mm
Weight	120000 g
