W WHITE
Y/G YELLOW/GREEN
B BLACK
R RED
INDOOR UNIT DIAGRAM
FAN MOTOR
POWER SUPPLY
BR BROWN
BL BLUE
ARE OPTIONAL
HAS NOT 2
NOTES THE PARTS OF DOTTED 1 , 2 AND 3
THE UNIT WITHOUT THE HEALTH FUNCTION
0010552145
Model:
HSU-12HS03/R2(DB)
HSU-09HS03/R2(DB)Domestic Air Conditioner
39
