Parts and Functions
12
OUTLET CONNECTING PIPING AND ELECTRICAL WIRING
INLET DRAIN HOSE
For multi-split type, the power plug is on the outdoor unit.
1
2
3
4
Indoor unit
Outdoor unit
Display board
Inlet
Air Purifying Filter
Vertical flap
(adjust up and down air flow.
Don't adjust it manually)
Horizontal louver
Air filter(inside)
Inlet grille
Power plug
(adjust left and right air flow)
(inside)
Outlet
Anion generator
(inside)
HSU-07HV03/R2
HSU-09HV03/R2
HSU-12HV03/R2
HSU-18HV03/R2
HSU-22HV03/R2
H2SM-18HV03/R2
H2SM-(9+12)HV03/R2
Air Conditioner
Edition:2006/1/10
