Number Name Refer No. Description Quality
Failure
Rate(%)
Remark
1
remote
controller
0010413791 None 1 0.2
*
2 battery 001A4600001 None 2 0.1
3
mounting
plate
0010101275
Fix mounting plate
according to
installation position
and pipe direction
0
4 drain pipe 001A0900011
Choose the place
that can drain
water and connect
pipe easily
1 0.1
5
connecting
pipe
----
The maximal
length of the
connecting pipe is
15m,the maximal
height between
indoor unit and
outdoor unit is 5m
1 0.2
*
6
connecting
wire
----
The conecting
methods include
ring terminal and
direct
terminal .Ring
terminal
connecting
method:Unscrew
the screws ,and
put it through the
ring of connecting
line ends,then
connect it into the
terminal block.
Direct terminal
connecting
method:unscrew
the screws,then
fully insert the
cable ends into.
.
1
0.2
*
7 manual 001A7265614 Operation 1 0
