Model:
Edition:2005/11/16
No. in
exploded
view
Spare parts number
Spare parts description in
english
Model Qty
Failure
rate(%)
The proportion
of the spare
part stock
Remark
1 001A1303126A Front grille HSU-22H03/R2(DB) 1 outdoor
2 001A1101038 Front panel HSU-22H03/R2(DB) 1 outdoor
3 001A2331024 Axial fan HSU-22H03/R2(DB) 1 outdoor
4 0010403895 Motor HSU-22H03/R2(DB) 1 outdoor
5 001A1301133 Bracket for fan motor HSU-22H03/R2(DB) 1 outdoor
6 0010705512 Condenser HSU-22H03/R2(DB) 1 outdoor
7 001A0100356 Side panel(left) HSU-22H03/R2(DB) 1 outdoor
8 001A1436182 Handle HSU-22H03/R2(DB) 1 outdoor
9 001A0100124 Panel(top) HSU-22H03/R2(DB) 1 outdoor
10 001A0100125 Service cover HSU-22H03/R2(DB) 1 outdoor
11 001A0100997 Side panel(fight) HSU-22H03/R2(DB) 1 outdoor
12 0010806797 Electric box assy. HSU-22H03/R2(DB) 1 outdoor
13 0010703520 4-wan valve coil HSU-22H03/R2(DB) 1 outdoor
14 --- Tube assy HSU-22H03/R2(DB) 1 outdoor
14-1 0010706999 Discharging tube assy. HSU-22H03/R2(DB) 1 outdoor
14-2 0010707000 Suction tube HSU-22H03/R2(DB) 1 outdoor
14-3 0010707001 Suction tube assy. HSU-22H03/R2(DB) 1 outdoor
14-4 0010707002 Discharging tube assy. HSU-22H03/R2(DB) 1 outdoor
15 0010706999 Capillary assy. HSU-22H03/R2(DB) 1 outdoor
16 0010705987 Service valve HSU-22H03/R2(DB) 1 outdoor
17 0010705989 Service valve HSU-22H03/R2(DB) 1 outdoor
18 --- Nut HSU-22H03/R2(DB) 1 outdoor
19 --- Service cover HSU-22H03/R2(DB) 1 outdoor
20 --- Nut HSU-22H03/R2(DB) 1 outdoor
21 0010707200 Compressor HSU-22H03/R2(DB) 1 outdoor
22 --- Rubber cushion HSU-22H03/R2(DB) 1 outdoor
23 --- Wire group HSU-22H03/R2(DB) 1 outdoor
24 001A17621543 Pad HSU-22H03/R2(DB) 1 outdoor
25 0010806754 Bottom plate assy. HSU-22H03/R2(DB) 1 outdoor
26 0010800009 Separating plate HSU-22H03/R2(DB) 1 outdoor
6.The spare parts price on net is FOB Qingdao term.
4,not need provided :The spare-part which is seldom damaged or the maintenance man could not maitmains.The spare parts may be air
freighted by the factory if they were damaged.The customer nees not stock in the spare-part warehouse,should be marked wit
1,The failer rate and the proportion of the spare-part stock are regarded as the reference of the stock for spare-parts;The first time should
be stocked accroded with the proportion of the spare-parts,and it should be adjusted with the actual quantity 3 m
2,easy-damaged;The spare-part which is often damaged and the customer must stock in the spare-parts warehouse,and should be marked
with"*"
3,possible damaged:The spare-part which is not often damaged like the easy damaged one and the customer may stock in the spare-part
warehouse accord with the actual case,should be marked with " ".
Domestic Air Conditioner
