Power Timing Running Indoor Outdoor Resumable
Faulty indoor thermistor Blinking Off Off * * Sensor in short or broken current
Faulty indoor thermistor Blinking On On * * Sensor in short or broken current
Faulty EEPROM Blinking On Blinking * * Wrong data or no EEPROM
Defrosting temperature sensor
in short or broken current
On On Blinking
Poor contact of components or poor
control board
Compressor discharge
temperature sensor in short or
broken current
Blinking On Off
Poor contact of components or poor
control board
Thermistor on wiring board in
short current
On Blinking On
Poor contact of components or poor
control board
Poor communication Off Off Blinking
1, Strong interruption 2, Poor wiring or
control board
Overheating discharge pipe Off Blinking Off
1,Short or excessive gas 2, High
（above 242v）or low (below 187v)
voltage 3,Jammed capillary tube
(compressor running fast with low
current input) 4,Faulty thermistor or
control board 5, High ambient
temperature
High AC current Blinking Blinking Off
1, Excessive gas 2, Low voltage 3,Poor
CT or control board 4, Faulty
compressor, high running current
High DC current Blinking Blinking On
1, Jammed compressor 2, Damaged
power module 3, High voltage (above
242v) or low voltage (below 187v)
Broken CT wire Blinking Off Blinking
1, Damaged control board 2, Short gas
3, Poor 4-way valve switch
Low voltage Off Blinking On
1, Low voltage input 2, Damaged control
board
Overload or high restrictions Blinking Blinking Blinking
1, Jammed compressor 2, Damaged
power module 3, Irregular heat emitting
gum 4, High voltage (above 242v) or low
voltage (below 187v)
Indoor motor warning (BP AC,
DP OF K SERIES)
HSU-18H03/R2(DB) Fault display code
The indoor motor finds no motor signal in a 10-sencond period after increasing the voltage. Running for 30 senconds
after cutting off the output voltage for the indoor motor, AC gives no motor signal but warning under new voltage for the
motor. Both he power light and running light blink twice at 1 Hz/s and then the power light, timing light and running light
blink once. The sames cycle goes on.
Fault codes Faulty Points
Power Timing Running Indoor Outdoor Resumable
Faulty indoor thermistor Blinking Off Off * * Sensor in short or broken current
Faulty indoor thermistor Blinking On On * * Sensor in short or broken current
Faulty EEPROM Blinking On Blinking * * Wrong data or no EEPROM
Defrosting temperature sensor
in short or broken current
On On Blinking
Poor contact of components or poor
control board
Compressor discharge
temperature sensor in short or
broken current
Blinking On Off
Poor contact of components or poor
control board
Thermistor on wiring board in
short current
On Blinking On
Poor contact of components or poor
control board
Poor communication Off Off Blinking
1, Strong interruption 2, Poor wiring or
control board
Overheating discharge pipe Off Blinking Off
1,Short or excessive gas 2, High
（above 242v）or low (below 187v)
voltage 3,Jammed capillary tube
(compressor running fast with low
current input) 4,Faulty thermistor or
control board 5, High ambient
temperature
High AC current Blinking Blinking Off
1, Excessive gas 2, Low voltage 3,Poor
CT or control board 4, Faulty
compressor, high running current
High DC current Blinking Blinking On
1, Jammed compressor 2, Damaged
power module 3, High voltage (above
242v) or low voltage (below 187v)
Broken CT wire Blinking Off Blinking
1, Damaged control board 2, Short gas
3, Poor 4-way valve switch
Low voltage Off Blinking On
1, Low voltage input 2, Damaged control
board
Overload or high restrictions Blinking Blinking Blinking
1, Jammed compressor 2, Damaged
power module 3, Irregular heat emitting
gum 4, High voltage (above 242v) or low
voltage (below 187v)
Indoor motor warning (BP AC,
DP OF K SERIES)
HSU-18H03/R2(DB) Fault display code
The indoor motor finds no motor signal in a 10-sencond period after increasing the voltage. Running for 30 senconds
after cutting off the output voltage for the indoor motor, AC gives no motor signal but warning under new voltage for the
motor. Both he power light and running light blink twice at 1 Hz/s and then the power light, timing light and running light
blink once. The sames cycle goes on.
Fault codes Faulty Points
Model: HSU-22H03/R2(DB)Domestic Air Conditioner
37
