4
Introductory Remarks
Description of coding rules of unit model
Coding rules and descriptions are as follows:
Applicable frequency:0(50HZ),1(60HZ)
Applicable voltage:3(220~230V),4(240V)
Refrigerant type:R1(R407C),R2(R410A)
Developing sequence :A,B,C,D...
Function code
R/H-heat pump
E-electric aided heating
Nominal cooling capacity (BTU/h)with the first two
numbers based on thousand unit
The structure code of indoor & outdoor unit:
S(wall-mounted),W(window type),P (cabinet type)
H-Abbreviation of Haier
2
3
4
5
6
7
1
8
9
L/C-cooling only
10 11
Examples:
HSU-22H03/R2(DB) represents wall-mounted split type heat pump DC inverter air conditioner.
The cooling
capacity is 22000BTU/h and the power supply is 230V/50Hz
the refrigerant is R410A.
Model: HSU-22H03/R2(DB)Domestic Air Conditioner
