Domestic Air Conditioner
5.2.1.3˖The speeds of increasing or decreasing the frequency of the compressor
The speed of increasing or decreasing the frequency rapidly 1 -----------1HZ/second
The speed of increasing or decreasing the frequency slowly 2 -----------1HZ/10seconds
5.2.1.4˖The calculation of the compressor’s frequency
1˅ǃThe minimum/maximum frequency limitation
AˊWhile refrigerating: ˢˉ˩˝˴ˉ is the maximum operation frequency of the compressor;
ˢˉ˩INˉ is the minimum operation frequency of the compressor.
BˊWhile heating: ˢˉ˩˝˴ˉ is the maximum operation frequency of the compressor; ˢˉ
˩INˉis the minimum operation frequency of the compressor.
1˅ǃThe frequency limitation which is affected by the environment temperature.
Heating mode:
Serial No. Temperature scope Frequency limitation
1 Wh_c<-12 Max_hz8 90 HZ
2 Wh_c<-8 Max_hz7 90HZ
3 Wh_c<-2 Max_hz4 90 HZ
4 Wh_c<5 Max_hz5 85HZ
5 Wh_c<12 Max_hz1 80HZ
6 Wh_c<17 Max_hz2 70 HZ
7 Wh_c<20 Max_hz2 55 HZ
8
Wh_c
≥
20
Max_hz6 45 HZ
Remarks: the above are the maximum frequency limitations of the complete appliance which are
affected by the environment, and they have nothing to do with the ability of the indoor unit.
Refrigeration/dehumidification mode::
Serial No. Temperature scope Frequency limitation
1 Wh_c<28 Max_hz1 45 HZ
2 Wh_c<32 Max_hz2 72 HZ
3 Wh_c<40 Max_hz3 80 HZ
4 Wh_c<48 Max_hz4 65 HZ
5
Wh_c
≥
48
Max_hz5 50 HZ
Remarks: the above are not only the maximum frequency limitations of the complete appliance which
are affected by the environment, but also the maximum ability limitation of the system. When the
starting ability is not the maximum, its maximum frequency limitation is calculated by the following
equations:
The frequency limitation which is affected by the temperature and under the condition of actual ability
˙the actural running system ability*the maximum frequency which is limited by the temperature and
under the condition of maximum ability/the maximum designing ability of the system
T=ě˄Ti*Pi˅/ěPi (Ti=|Tst_i-Tnh_i the indoor environment temperature| ;Pi˙i the ability of
the indoor unit)
Refrigeration/dehumidification:
T
<1
˙1 ˙2 ˙3
≥
4
The percentage of the
rated frequency P
50% 70% 100% 120% 140%
(Wh_c= environment temperature)
