7.3 Error Codes and Description indoor display
Code indication
Description
Reference
Page
Indoor
Outdoor
(LED1 flash
times)
Indoor ˂ Outdoor
E7 15
Communication fault between indoor and
outdoor units
Page .59
Indoor Malfunction
E1 / Room temperature sensor failure Page .51
E2 / Heat-exchange sensor failure Page .51
E4 / Indoor EEPROM error Page .58
E14 / Indoor fan motor malfunction Page .52
Outdoor
Malfunction
F12 1 Outdoor EEPROM error Page .58
F1
2
The protection of IPM Page .55
F22
3 Overcurrent protection of AC electricity for
the outdoor model
Page .63
F3 4
Communication fault between the IPM and
outdoor PCB
Page .56
F19 6 Power voltage is too high or low Page .61
F27 7 Compressor is lockrotor or stopt momentary ----
F4 8 Overheat protection for exhaust temperature Page .57
F8 9 Outdoor DC fan motor fault Page .54
F21 10 Frost-removing temperature sensor failure Page .51
F7 11 Suction temperature sensor failure Page .51
F6 12 Ambient temperature sensor failure Page .51
F25 13 Exhaust temperature sensor failure Page .51
F11 18 deviate from the normal for the compressor Page .62
F28 19 Loop of the station detect error Page .62
F2 24 Overcurrent of the compressor Page .63
F23 25
Overcurrent protection for single-phase of the
compressor
Page .63
F36 39
Middle part of condenser temperature sensor
failure
----
