Haier HSU09VHGDB-W Service Manual

70
Domestic air conditioner
Removal of procedure
Please close the panels
before start the removal
procedure of front grille.
one side to another to
release each axis.
until it is on the
horizontal position,
and then release the
pivots on both sides of
the unit to remove the
front panel.
9.2 Remocal of front panel
HSU12HG(DB)-SM
