7
(2) Setting ECO parameter of heating
Turn on the wired controller and select heating mode, adjust the setpoint temperature to 16°C. Hold
and for 5s to set the ECO parameter of heating which will appear in temperature display
area and the default value is 26. The parameter can be adjusted by
or ranging from 16 to 30.
Press
to conrm after completing the settings. If no keys are pressed within 10s, the parameter
adjustment interface will exit automatically and the previous change will be invalid.
ECO parameter of heating limits the maximum setpoint temperature in heating mode. For example,
if ECO parameter of heating is set to 26, as a result, the range of the setpoint temperature in heating
mode is 16°C~26°C after the ECO function is activated.
Operation
When the backlight is lit up, hold and for 5s to activate the child lock function. After function
is turned on, the icon
will display statically. As a result, all keys are invalid. If you press any of the
keys, the icon
will blink 3s to indicate no keys can be pressed.
When the child lock function is turned on, lit up the backlight, then hold
and for 5s to turn o
child lock function.
Child lock function
If the current temperature unit is °C, adjust setpoint temperature to the maximum value and hold
for 15s to switch to °F.
If the current temperature unit is °F, adjust setpoint temperature to the minimum value and hold
for
15s to switch to °C.
°F/°C switching (only valid for part of models)
