Haier HW-BA101ABT User Manual

15
Wired Controller Wiring Instruction
Installation
1. Use a at-blade screwdriver to pry open the A and B positions and separate the front and rear
panels of the wired controller.
A B
2. Use the screws to secure the wired controller back panel.
3. Connect the communication cable to the rear port of the wired controller. The connection method is
as follows:
C
A
B
Red
Yellow
White
