Haier L26F6 Service Manual

7-3. Wiring Connection Diagram
1
NO. Name Parts number
1
2
3
Cable(For Keyboard)
0090403399C
4
Cable(For Speaker)
0090402849A
5
Cable(Power For Audio Amplifier)
0090400647D
6
Cable(For Remote)
0090401643B
LVDS Wire
0090402070A
Cable(Power For Mainboard)
0090403469E
2
3
4
5
6
NO. Name Parts number
1
2
3
Cable(For Keypad)
4
Cable(For Speaker)
0090401643D
5
Cable(Power For Audio Amplifier)
6
Cable(For Remote)
0090402750B
LVDS Cable
0090402070B
Cable(Power For Mainboard)
0090402469
7
Cable(For Ornamental Light)
0090402849A
/)
1
2
3
4
5
6
7
/)
(
+
8
Cable(For Ornamental Light)
0090402750B
7
Cable(For Backlight)
0090402054A
7
8
Service Manual
Model No.:
/)
53

Haier L26F6 Specifications

General

Screen Size	26 inches
Display Technology	LCD
Aspect Ratio	16:9
Response Time	8 ms
Viewing Angle	170° (H) / 160° (V)
Resolution	1366 x 768
Input Ports	HDMI, Component, Composite, VGA
