Haier LE40B50 - Connection Procedures; Antenna Connection Guide; PC Input Setup

-6-
INSTALLATION
STEPS:
PC
Be sure both the TV and computer are
set to Power off.
1.Connect VGA and audio cable.
2.Connect the power cord.
3.Power on the TV, switch to PC mode.
4.Power on the PC.
This sequence is very important.
Note:
Aerial connections: IEC(female).
Input impendance: 75 unbalanced.
ANTENNA
HDMI 2 HDMI 1 USB
AV OUT/AV2 IN PC AUDIO
VGA RF
