Dimensions of the
setup ladder
(sides extended to maximum)
- Stepladder
A = Width
B = Depth (support surface)
- Single ladder
A = Width
B = Depth (support surface)
Dimensions of the
ladder collapsed
(Supplied state)
A = Length
B = Width
C = Depth
Dimensions of the
ladder collapsed
(Storage)
A = Length
B = Width
C = Depth
Highest possible
load capacity
Weight of the ladder
Number of ladder rungs
Reference person for body
size and reaching height
A = highest possible
reaching height
B = highest possible
standing height
- Stepladder with sides
extended to the maximum
- Single ladder with sides
extended to the maximum
Dimensions of the
setup ladder
(sides extended to maximum)
- Stepladder
A = Heigh
- Single ladder
A = Length of the ladder
B = Heigh
- Stepladder
(step adjustment)
A = maximum height
compensation
