Hailo ProfiStep multi - Page 14

15
GB
1
2
Insert sleeves into the
stabilizer bars.
Then screw the pre-
assembled stabilizer bars
to the scaffolding ladder.
Attaching the
stabilizer bars
Assembling the wheels
First assemble the ladder
rungs with the threaded
rod and the guide stops.
On both sides, attach one
short and one long wheel
stay respectively to the
rungs on the ladder using
wing-nuts, as shown.
Attach the two wheels to
the wheel stays using
screws.
