19
GB
1
2
Attaching the
stabilizer bars
Insert sleeves into the
stabilizer bars.
Then screw the pre-
assembled stabilizer bars
to the scaffolding ladder.
First assemble the ladder
rungs with the threaded rod
and the guide stops.
On both sides, attach one
short and one long wheel
stay respectively to the
rungs on the ladder using
wing-nuts, as shown.
Attach the two wheels to the
wheel stays using screws.
Assembling the wheels
