21
GB
First assemble two ladder
rungs with threaded rods
and guide stops (3
rd
rung
from the top).
Hang the working platform
from the pre-assembled
ladder rungs, and apply
the U-shaped washers.
Screw long side profiles to
angle profiles and secure
to the working platform
using the U-shaped washer
and wing nut.
Insert short side profiles
and lock in place with con-
necting pins.
6
7
Attaching the
working platform
First assemble the four
upper ladder rungs with
threaded rods and guide
stops.
Insert end caps into four
rung stays.
Mount the rung stays and
first fasten using wing nuts
only to the lower rungs.
Assembling the
rung stays
