Hakko Electronics HJ3100 - CHARACTERISTICS AND SPECIFICATIONS.

©1997, AMERICAN HAKKO PRODUCTS, INC.
ALL RIGHTS RESERVED
4
CHARACTERISTICS AND SPECIFICATIONS.
CONTROLS.
The only control for the HJ3100 is a power switch. The motor is equipped with a thermal overload sensor, which will
turn power off should the motor temperature exceed 160 to 180
0
F. Units manufactured after August 15, 1997 (serial
numbers HJ3100-7001 and up) are fitted with circuit breakers as well.
TABLE I. TECHNICAL SUMMARY.
MOTOR AND BLOWER DATA.
HJ3100, -02, -04 HJ3100-01, -03
C
HARACTERISTIC
@100
V. @115 V. 230 V
X
INPUT VOLTAGE
100
V, 50/60 HZ 115 V, 50/60 HZ 230 V, 50/60 HZ
CURRENT, AMPERES
4.25 3.0 1.50
POWER CONSUMPTION, WATTS
365 350 350
MOTOR POWER RATING, HP
1/5 1/5 1/5
VACUUM PUMP RATING, ONE PORT, FT
3
/MIN
†
@ 60 HZ
115 122 124
VACUUM PUMP RATING, TWO PORTS, FT
3
/MIN
†
150 154 155
VACUUM PUMP RATING, TWO PORTS, FT
3
/MIN
‡
190 202 202
VACUUM PUMP RATING, TWO PORTS, FT
3
/MIN
♪
180 190 190
FREE STREAM AIR FLOW. WITH TWO PORT COVER
220 235 235
FREE STREAM AIR FLOW, WITH FOUR PORT COVER
260 280 280
†
WITH PRE-FILTER AND 999-137 HEPA/CARBON FILTER INSTALLED.
‡
WITH 999-178 PARTICULATE FILTER INSTALLED.
♪
WITH PRE-FILTER AND 999-182 CARBON FILTER INSTALLED.
X
FASCO 70624794, REV
N
A
Noise level at 2 meters (HJ3100, -01, -02): 59 dBA without optional 999-171 muffler
54 dBA with optional 999-171 muffler
Filters:
Pre-filter Per Hakko specification 999-136
HEPA/carbon filter Per Hakko drawing 999-137
Particulate filter Per Hakko drawing 999-178
Carbon filter Per Hakko drawing 999-182
Dimensions (all dimensions in inches; see Figure B-1 for outline drawings):
Width 11.00
Depth 9.00
Height 18.00
Weight (approx.) including filters 18 lbs.
TABLE II. ENVIRONMENTAL SPECIFICATIONS.
A
MBIENT OPERATING TEMPERATURE 0
O
TO 50
O
C (32
O
TO 122
O
F.)
S
TORAGE TEMPERATURE -40
O
TO 125
O
C (-40
O
TO 257
O
F.)
A
MBIENT OPERATING HUMIDITY 90% RELATIVE HUMIDITY MAXIMUM (NON-CONDENSING)
S
TORAGE HUMIDITY 90% RELATIVE HUMIDITY MAXIMUM (NON-CONDENSING)
