EB+ CAN Hub
Installation
Guide
5
2020 Innovative Vehicle Solutions
EBS
18 m maximum ISO 7638 cable length (ISO 11992 pin 6 & 7)
Suzie
7 m
Towing
15 m
Towed
18 m
CAN Hub
EBS
Suzie
7 m
Towing
15 m
Towed
18 m
EBS
The ISO 11992 CAN Bus is limited to 40 meters, where 22 meters is allocated for the truck (towing vehicle + Suzie
connection) and a maximum of 18 meters for the trailer (towed vehicle).
The maximum length to an ISO 7638 connector installed at the rear of the trailer is 15 m.
