Halemeier GmbH & Co.KG - Lange Straße 51 - D 49326 Melle Neuenkirchen
3
25.350.72
11.04.2017
c MM 3 q m
S-Mier basic MulWhite²
Typ: HA-MW2 -E /-SMBS
/
Important Safety Informaons:
1. During installaon, maintenance and repairs the system must be completely disconnected from the mains electricity supply. Disconnect the mains plug and secure it
against being inserted again.
2. Only use approved installaon materials or system accessories for mounng.
3. Damage caused by incorrect connecon will invalidate warranty entlement.
4. Cables should be installed in a way that connecon points are not subjected to pull or tear.
5. To avoid hazards, any damaged external exible lead of the light must only be replaced by the manufacturer or its designated customer care representave.
6. No warranty cover if unauthorized modicaons are made.
Keep installaon instrucons in a safe place!
Please keep these installaon instrucons aer installing the product so that any later changes can be carried out in the proper manner.
Wireless hand-held transmier
Power supply:
Baery:
Baery life:
Transmission frequency:
Transmission range:
Stand-by current consumpon:
Transmission operaon current consumpon:
Number of possible receivers:
Receiver
Nominal voltage:
Switching capacity:
Load types:
Number of possible hand-held transmiers:
Channel allocaon:
Recepon frequency:
Connecons:
3 VDC
1x Lithium-Knopfzelle (CR2032)
ca. 8 months at average operaon
433,9 MHz
Max. 30m in free eld
10μA
10mA
unlimited
12DC
12VDC max. 36W
LED MulWhite² Leuchten
max. 5
automac for transmier programming
433,9 MHz
LED mini plug M1
m
Do not dipose of in household waste! Disposal to be carried out in accordance with local regulaons.
Transmission control LED
Dim (+)
Dims up to 100%
Master buon
for full switching on and off of all channels.
Last switching status is saved.
short press - On/Off
1-4 memory locaons
for personal colour seng
teach in/overwrite by
pressing and holding down the desired
buon (approx. 4 seconds)
CR 2032 /3V
Cold white buon
changed the cold light to 100%.
Warm white buon
changed the warm light to 100%..
Dim (-)
Dims up to 0%
100
16
45
160160
48
10,7
105
The wireless transmier is immediately ready for operaon with the receiver
contained in the set once the baery safety strip has been removed.
Technical details
