Haltech ic-7 User Manual

IC-7 DISPLAY DASH OVERVIEW
What’s in the box?
• 1 x Haltech IC-7 Display Dash
• 1 x HT-131001 34 Pin Main Connector Harness
• 1 x HT-130028 DTM-4 to DTM-4 CAN
Extension Cable (3.0m)
• 1 x HT-070013 USB to M5 Right Angle (400mm)
2
This quick start guide will walk you through the
installation of a Haltech IC-7 Display Dash into
a vehicle already fitted with a Haltech ECU.
This guide is accompanied by the Help
information located in the Haltech IC-7
software, located on the USB key provided.
More information is available from the Haltech
website: www.HALTECH.com
• 1 x HT-070001 USB Cable 2.0M
• 3 x M5 x 8mm Mounting Screws
• 1 x USB Key
• 1 x Quick Start Guide Booklet
• 1 x Haltech Product Catalogue
Optional Mounting Options (purchased separately)
Mounting Bracket
with Integrated Visor
HT-060071
Mounting Bracket
HT-060070
