OUTPUTS
Ignition 12
Injector (peak and hold) 18
Digital Pulsed Outputs (DPO) 8
Power for Ignition Switch 1
Half Bridge Outputs (HBO) 4 (2 x H-Bridges/DBW throttles)
8A High Current Outputs (8A HCO) 12
25A High Current Outputs (25A HCO) 4
INPUTS
Analog Voltage Inputs (AVI) 23
Differential Engine Position Inputs 2 (Trigger and Home)
Synchronised Pulsed Inputs (SPI) 10
Knock Inputs 2
Universal Wideband Controllers (NTK/LSU 4.9) 2
Ignition Switch Input 1
OTHER
Inertial Measurement Sensor Onboard, 6 Axis
4 Channel Oscilloscope 50kSa/s per channel, 2ms/Div limit,
optional external trigger
5V Sensor Supply 2
8V Sensor Supply 1
Sensor Ground 2
Spare Ground pins for shields, sensors and low current CAN devices 2
COMMUNICATIONS
CAN Bus Networks 1000, 500 or 250 kbit/s 3
High Speed USB 2.0 (USB-C interface) 480 Mbit/s connection 1
PowerupoverUSB Datalogging,settingsandrmwareupgradeavailable
Wi-Fi 900 kB/s datalog extraction. Hardware lockout for security
DATA LOGGING
Location Onboard
Storage 512MB
Max sampling frequency 1kHz
Maximum channels per log 300
DIMENSIONS
Enclosure (Not including connector protrusion) 257 x 132 x 51 mm (10.1 x 5.2 x 2 in)
Overall (Including connector protrusion) 257 x 163 x 61 mm (10.1 x 6.4 x 2.4 in)
Weight 1.50 kg (3.307 lb)
Operating Temperature (external) -40 to 85°C (-40 to 185°F)
12 x Onboard Temperature Sensing Zones ECU: -40 to 125°C (-40 to 255°F)
PDM: -40 to 150°C (-40 to 300°F)
ELECTRICAL
Power Supply (across power terminals) 8 to 22V
Internal positive inline fuse (not user-serviceable) 32VDC 200A
No output static current draw <1A
Low Power Mode (USB) 4 to 5.5V
Static current draw from USB port 400mA
