A
Remove the handlebar stem
EN Unscrew the top screw and cap, and the two horizontal
screws located on the handlebar stem (pic. 1), so that you can
release the handlebar stem (pic. 2).
AHEAD BRACKET for OBSERVER
Pic. 1
Pic. 2
