Parts and Features
To order parts, visit:
hamiltonbeach.com/parts
1 Water Reservoir Lid
2 Water Reservoir
3
Brew Lights (under Water
Reservoir)
4 Display Panel
5 Keep Warm Indicator Light
6 Base
7 Keep Warm Plate
8 Brew Basket Holder & Scale
9 Shower Head
10 Removable Brew Basket
11 Drip Stop
12 Drip Cup
13 Carafe Lid & Mixing Tube
14 Carafe
15 Removable Reusable Filter
16 Water Filter Lid
17 Water Filter Pod
18 Water Filter Base
1
2
(with select models)
4
10
11
14
12
13
16
17
18
5
7
8
6
(with select models)
3
9
15
