5
Parts and Features
*To order parts: visit hamiltonbeach.com
NOTE: All Jars have fixed multi-purpose blades�
Before first use: After unpacking appliance, wash everything except
Base in hot, soapy water� Dry thoroughly� Wipe Base with a damp cloth
or sponge� DO NOT IMMERSE BASE IN WATER� Care should be taken
when cleaning inside of Jar as the cutting blade assembly is very sharp�
1.5 Liter
Multi-Purpose
Jar*
1.0 Liter
Multi-Purpose
Jar*
Tamper*
(1.0 L Jar
only)
0.5 Liter Dry Jar*
Scraper*
Base*
RESET
Button
Bottom Rear
of Base
PULSE Button
Speed Selection Dial
START/STOP Button
Control Panel
(detailed view on
next page)
ON/OFF (I/ )
Power Switch
Square
Gasket*
Filler Cap*
Round
Gasket*
Lid Clips (2)
Lid
Lid
Clips (2)
Lid
Interlock
Lid
Interlock
Lid
Lid
Interlock
Lid Clips (2)
