4
Parts and Features
To order parts, visit:
hamiltonbeach.com/parts
Before first use: Wash all removable parts in hot, soapy water. Rinse and
dry. Brew one cycle with water on each side and discard water.
1 Lid Latch
2 Single-Serve Lid
3
Brown Needle Holder with
Black Seal (removable)
4 Piercing Needle
5 Funnel
6 Control Panel
7 Cup Rest (removable)
8 Warming Plate
9
60 oz. Reservoir with Lid
(removable)
10 Carafe Brew Basket (removable)
11 Swing-Out Brew Basket Holder
12 Carafe
13
Green Single-Serve Pod Holder
(removable)
14
Green Single-Serve Brew
Basket (removable)
2
4
3
1
7
6
14
13
10
9
11
5
12
8
