Hamlet Solution 5 Widescreen User Manual

Page 10
BK 700 Specific
5 Air inlet controls
5.1 Location and operation of the controls
Your stove has two air inlet controls. These are located either on the stove body or the
stove door.
5.1.1 Primary air
The primary air inlet provides under draught to the base of the fire chamber.
Primary air enters the appliance through the inlet near to the bottom of the fire door. Your
stove has a control slider to adjust the flow of the primary air.
Sliding the knob to the right will increase the amount of air intake to the stove, as shown in
position (in figure 1). To decrease, push the slider to the left, as shown in position (in figure
2).
Secondary Air Control
(Airwash)
Primary Air Control
Fig. 1. Fully Open Position Fig. 2. Fully Closed Position
SOLUTION Stove User Guide
