Hamlet Solution 5 Widescreen User Manual

5.1.2 Airwash system / Secondary air
The secondary air provides an overdraught of air together with supplying air in front of the
glass viewing panel within the door assembly. This is know also as the airwash system.
The airwash/secondary air inlet has an internal sliding plate with slots, housed inside the
body of the appliance and is located above the top of the fire door.
Sliding the control knob to the right as far as it will go, achieves the fully open position, see
figure 3. Sliding it to the left will shut down the air inlet slots as shown in figure 4.
Fig. 3. Fully Open Position
Fig. 4. Fully Closed Position
BK 700 Specific
Page 11
SOLUTION Stove User Guide
NOTE : The Hamlet Solution 5 Widescreen models that are fitted with the mechanical
stop for smoke control areas, then please note that the airwash will not fully close as in Fig.
4.
NOTE : DO NOT COVER OR PARTIALLY OBSTRUCT THE AIR INLET OPENINGS
FOR THE APPLIANCE.
