PART IDENTIFICATION TABLE
Part Description Visual Aid ( Not to Scale ) Part Number
Multi Fuel Kit
(includes Fixings)
MFKITINSET5
* Grate bar support
( Back Landing)
1 x AFS1327
* Grate bar comb &
Extension
1 x AFS1413
* Grate Bar 5 x AFS0001
* Plus / Minus bracket
1 x AFS1412
** Inner Wood Cover Plates
(Includes Fixings
1 x AFS1404
** Outer Wood Cover Plates
(Includes Fixings
1 x AFS1333
** Wood Burning Tray
1 x AFS1401
* components included in Multi-Fuel Kit ( MFKITINSET5 )
** components standard with wood burning version of stove as despatched
Not included in factory fitted multi-fuel version
