Hamlet Solution Inset
Page 5
Fig 4a
Insert Comb extension
though the stove body
Section views are for clarity
Fig 4b
Slot and hole aligned
vertically
ASSEMBLY PROCEDURE
Fig 4c
Fig 4d
Left and right end
comb insertion
Left hand end in
left landing
Right hand end
inserted into comb
extension
