7. Replace any other parts previously removed. Fasten echo wiring panel on top of
line panel cover and connect all wires as shown in figure 5.
8. Check for proper operation. If it should happen that the echo cabinet
sounds with the switch in main position and the main cabinet sounds with the switch
in echo position. interchange the main and echo cable wires at the echo wiring
panel.
INSTALLING KIT IN CONCERT MODEL E CONSOLES
In this model the preamplifier is located so far from the line panel that the blue,
green, and black wires from the echo panel must be extended to reach the
preamplifier. In addition, the black and red cable wires must be extended to reach
the echo panel. Otherwise the installation may be made as described above.
