6
HOOK-UP
 An example of the Hook-up of the SK2
Leslie Mode Switch
CU-1 (optional)
AC Adaptor
MIDI cable
Expression Pedal
EXP-50 (optional)
 Connect the MIDI OUT on this unit to the MIDI IN of the SK2 by means of a MIDI cable.
 Connect the AC adaptor AD1-1508 / AD3-1508 to the DC IN on this unit.
  e power on this unit is not turned “On” or “O ” with the SK2. Pull out the AC adaptor from the AC outlet a er
each use.
