3
A. Structure
1. There are two temperature setting switch. One is on the top of electrical box;
another, it can adjust the temperature of oil. Another is inside the box and it will cut
of electricity when the temperature is 230 centigrade.
2. Heating tube can be turned in order to clean heating tube and oil bowl.
3. There is a timer alarm system at the range from 0 to 99 minute. User can set the
time to fry food and the system will be on when time is up.
B. Technical parameter
C. Transportation and storage
During transportation, the machine should be careful handled and prevent from shaking.
The packaged machine should not be stored in open air long. It should be put in a
ventilated warehouse without causticity gas. And it should not be put up side down. If it
needs to be stored in open air temperately, measurement against raining in needed.
D. Safety Guarding
a) This product should be put on a smooth place. Its two sides are recommended be
put more than 10cm from any obstacles and its back is over 20cm.
b) The voltage should be coordinated with the voltage in data plate. When the
machine is running the voltage should not exceed±10.
c) Do not put anything in front of the switch. Install fuse and leak electricity protector.
d) Use wire at least 2.5mm² and make sure the well ground connection for safety
sake.
e) Before using this product, please check al parts and power supply and ground
connection.
f) The connection and installation of this product should be done by professionals.
g) Power cord draws with yellow and green two ground wires. User should use copper
bolt to link up this ground wire and another safe one.
h) If user change power cord user should use YCW oil-resisting wire with yellow and
green two ground wires. Count to use by 8-10A/mm²
i)
