HAMPTON BAY 10856 - Assembly; Installing the Pump; Attaching the Pump Cover

5 HAMPTONBAY.COM
Please contact 1-877-527-0313 for further assistance.
Assembly
1
Installing the pump
2
Attaching the pump cover
□ Place the pump (B) in the base (A).
□ Position the electrical cord through the groove on the back
of the base (A).
□ Assemble the pump cover (D) to the fountain back.
□ Close the pump cover (D).
B
A
D
