Assembly (continued)
Attach the arms (E) to the seat (D) using M8x90 combination bolts, washers and nuts (BB) and
M6x85 combination bolts, washers and nuts (EE).
Once all of the bolts are in place, fully tighten the bolts.
Attaching the arms to the seat
2X
D
E
BB
BB
EE
EE
E
BB
EE
E
