26
CHARGING AND LOAD STATUS
STATUS LAMP COLOUR INDICATION SIGNIFICANCE
Charge status
indicator
Green On Charging in progress
Green O No charging
Green Flashing rapidly Overvoltage, battery
Load status indicator Green On Load connected and
switched on
Green O Load disconnected/not
connected
Green Flashing slowly Overload
Green Flashing rapidly Short circuit
BATTERY STATUS INDICATOR
INDICATOR 1 INDICATOR 2 INDICATOR 3 INDICATOR 4 BATTERY STATUS
Flashing slowly – – – Undervoltage
Flashing rapidly – – – Over-discharge
Battery status for increasing voltage (charging)
¤ ¤ – –
12.8 V < Ubat <
13.4 V
¤ ¤ ¤ –
13.4 V < Ubat <
14.1 V
¤ ¤ ¤ ¤ 14.1 V < Ubat
Battery status for decreasing voltage (discharging)
¤ ¤ ¤ –
12.8 V < Ubat <
13.4 V
¤ ¤ – –
12.4 V < Ubat <
12.8 V
¤ – – – Ubat < 12.4 V
¤ = LED indicator on
– = LED indicator o
